Aluminium windows and doors

COR GALICIA PREMIUM C16

Aluminium outside, solid timber inside, in the same thermally broken system.

Section through the CORTIZO COR Galicia Premium C16 system, official manufacturer image

Galicia Premium C16 answers a requirement that comes up often in quality residential projects: aluminium towards the street, where weather resistance and freedom from maintenance matter, and timber towards the inside, where touch and colour matter.

The timber is not a decorative facing but part of the system, with its own polyamide bar on the frame and on the sash. The species published by CORTIZO are American oak, sapele and Scots pine, with other options on request.

Request a quote for COR Galicia Premium C16

At a glance

The values that decide the choice

Constructionaluminium outside + timber inside
Uwfrom 1.1 W/m²K
Acousticup to Rw 40 dB
Dimensionsframe 66.4 / sash 85.3 mm

Specifications

The data from the official data sheet

COR GALICIA PREMIUM C16

A composite system, with aluminium outside and timber always inside. The glazing rebate is declared separately for the sash and for the fixed light.

Section through the CORTIZO COR Galicia Premium C16 system, official manufacturer image

Characteristics

Thermal transmittance
Uw ≥ 1.1 W/m²K
Glazing
maximum: sash 40 mm, fixed light 30 mm; minimum: sash 18 mm, fixed light 8 mm
Sound insulation
maximum Rw = 40 dB
Frame sightline
66,4 mm
Sash sightline
85,3 mm
Profile thickness
window 1.5 mm / door 1.6 mm
Polyamide bar
frame 14.8 mm / sash 16 mm
Maximum dimensions / leaf
W 1,400 mm × H 2,400 mm
Maximum weight / leaf
100 kg
Extrusion alloy
6063 T-5

Classes achieved in testing

Air permeability (UNE-EN 12207)
Class 4
Watertightness (UNE-EN 12208)
Class E1050
Wind resistance (UNE-EN 12210)
Class C5
Reference test specimen
1.23 × 1.48 m / 2 leaves
Testing verified by
ALUMINIOS CORTIZO S.A.U.

Opening configurations

  • Inward: side-hung, tilt and turn, and bottom-hung.

Finishes

  • Outside, aluminium: two-tone possible
  • Outside: powder coating (RAL, mottled and textured), to Qualicoat >60 microns
  • Outside: wood-effect coating, to the Qualideco standard
  • Outside: anodising, to Ewwa Euras / standard class 15, optionally classes 20 and 25
  • Inside, always timber: American oak, sapele, Scots pine; other options on request
  • The timber is finished with a clear, satin, solvent-free eco lacquer

Download the data sheetOfficial CORTIZO data sheet – PDF · 250 KBCOR GALICIA PREMIUM C16

The thermal transmittance values published by CORTIZO are minimum values for the system, conditional on the typology, on the dimensions of the joinery and on the glazing unit. The actual value of an assembly is established by calculation, on the configuration actually ordered.

From system to finished joinery

What we do with this system

Choosing the configuration

The system offers a range; the project asks for a value. We settle the version, the glazing unit and the typology from the actual requirements of the building, not from the maximum on the data sheet.

Calculation on the actual assembly

The transmittance of a window depends on the frame-to-glass ratio. We calculate it on the actual dimensions of the openings, not on the laboratory specimen.

Our own production

Cutting, machining, assembly and glazing in our own workshop in Baia Mare, on original CORTIZO profile and with hardware approved for the system.

Installation and handover

We install with our own teams, including abroad, and hand the job over with its documents. The warranty is the one published on our warranties page.

Next step

Do you want COR Galicia Premium C16 on your project?

Send us the window schedule or the drawings. We will come back with the right version from the family, with the thermal calculation on the actual openings, and with the price.

Request a quote
