MALLORQUINA SHUTTERS

The classic louvred shutter, with fixed or adjustable slats and 1 to 4 hinged leaves.

Mallorquina is the classic Mediterranean shutter, made in aluminium: louvred side-hung leaves, fitted outside the window. The louvres can be fixed or adjustable, which changes the way it is used completely — from permanent shading to fine control of the light.

Besides shading, a closed shutter also improves the transmittance of the assembly. CORTIZO publishes a correspondence table between the transmittance of the window alone and that of the window + shutter assembly.

Request a quote for Mallorquina

At a glance

The values that decide the choice

Frame / sash40 / 48 mm
WindClass 5
Maximum sizes1.600 × 2.500 mm
Leaves1, 2, 3 and 4, side-hung

Specifications

The data from the official data sheet

MALLORQUINA SHUTTERS

A louvred side-hung shutter, available with fixed or adjustable louvres.

Section through the CORTIZO Mallorquina system, official manufacturer image
The technical drawing of the system, published by CORTIZO

Characteristics

Frame sightline
40 mm
Sash sightline
48 mm
Profile thickness
window 1.3 mm / door 1.5 mm
Maximum sizes
W 1,600 mm × H 2,500 mm
Maximum weight / leaf
100 kg
Thermal resistance
ΔR = 0.08 m²K/W (shutter + air cavity)
Extrusion alloy
6063 T-5

The effect of the closed shutter on the transmittance of the assembly

Uw – transmittance of the window (W/m²K)Uws – transmittance of window + shutter (W/m²K)
0,80,75
1,00,93
1,21,09
1,41,26
1,61,42
1,81,57
2,01,72
2,21,87
2,42,01
2,62,15
2,82,29
3,02,42
3,22,55

The thermal resistance of the shutter and of the air cavity between shutter and window: ΔR = 0.08 m²K/W.

Classes achieved in testing

Resistance to wind load (UNE 13659:2004)
Class 5
Reference test specimen
1.50 × 1.50 m / 2 leaves
Testing verified by
ALUMINIOS CORTIZO S.A.U.

Opening configurations

  • Side-hung with 1, 2, 3 and 4 leaves.

Infill options

  • Fixed louvres.
  • Adjustable louvres.

Finishes

  • Powder coating (RAL, mottled and textured), to Qualicoat >60 microns
  • Wood-effect coating, to the Qualideco standard
  • Anodising, to Ewwa Euras / standard class 15, optionally classes 20 and 25

Download the data sheetOfficial CORTIZO data sheet – PDF · 118 KBMALLORQUINA SHUTTERS

The thermal transmittance values published by CORTIZO are minimum values for the system, conditional on the typology, on the dimensions of the joinery and on the glazing unit. The actual value of an assembly is established by calculation, on the configuration actually ordered.

From system to finished joinery

What we do with this system

Choosing the configuration

The system offers a range; the project asks for a value. We settle the version, the glazing unit and the typology from the actual requirements of the building, not from the maximum on the data sheet.

Calculation on the actual assembly

The transmittance of a window depends on the frame-to-glass ratio. We calculate it on the actual dimensions of the openings, not on the laboratory specimen.

Our own production

Cutting, machining, assembly and glazing in our own workshop in Baia Mare, on original CORTIZO profile and with hardware approved for the system.

Installation and handover

We install with our own teams, including abroad, and hand the job over with its documents. The warranty is the one published on our warranties page.

Next step

Do you want Mallorquina on your project?

Send us the window schedule or the drawings. We will come back with the right version from the family, with the thermal calculation on the actual openings, and with the price.
